Software for Pre-CAD systems design

Design Tools

Mechanomy develops software libraries that aide modeling of mechanical systems, focusing on the essential and difficult period before CAD design, prototyping, and FEA. This page gives an overview of our released work. We use this software internally in our targeted prototypes and exemplary systems, see our demos for some examples.

We're always looking for new projects, let us know if you would like to partner on something new or engage our development services.


BeltTransmission graphically designs 2D belt transmissions:


SortedTable creates a table with sortable columns and convertible units:


SimpleGraph - creates interactive line graphs via a simple syntax:


ViewModel - displays interactive 3D models:


UnitConverter - creates interactive unit converters:
